Gantry CNC Plate Drilling Machine
The Gantry CNC Plate Drilling Machine is mainly used for drilling connecting plates and floor boards in steel structures, iron towers, bridges, mechanical processing, and other related industries. The machine supports drilling of through holes, blind holes, step holes, and hole end chamfering, and is equipped with an automatic workpiece clamping system to ensure stable and precise operation.- Category: Plate Drilling Machine
- Model: KR-PD
- Drilling Diameter: 12–50 mm
- Working Width: 1600 mm
- Working Length: 2000 mm
- Working Thickness: 0–100 mm
- Working Power: 5.5 kW
- Working Accuracy: ±0.5 mm
- Working Speed: 120–560 mm/min
- Moving Speed: 180 mm/s
- Certification: CE
Machine Features
CNC Drilling and Milling Machine for Metal Plate, Flange and Tube Sheet
- Servo slide drilling unit heads,with the fuction of drilling holes,reaming,chamfering angle,milling of groove,can work together,or work separately.
- Automatically find pot to dill holes in X,Y axis.Spindle rotation speed and feed verlocity are stepless adjustment.
- T-groove is set on lathe bed,using pressure plate to clamp workpiece.
- To seek workpiece center in hand-operated wheel,thimble.
- Programming software based on WINDOWS platform with CAD connection, fast and convenient programming, and visual previewing.
- Automatic chip removal, coolant circulation cooling.
- Key machinery, hydraulic pressure, electric components are chose from famous cooperation domestic and abroad.
- First choice equipment of tube plate drilling in heat exchange,chemical & mechanical industry.
| Item | Parameter | Unit | YM-PD2016 |
|---|---|---|---|
| Max Working Size | Length × Width | mm | 2000 × 1600 |
| Overlay Thickness | mm | 100 | |
| Drilling Spindle | Number of Spindle | pcs | 1 |
| Spindle Model | – | Morse 4# Cone Hole | |
| Spindle Speed | r/min | 120–560 (Stepless Inverter) | |
| Feeding Type | – | Hydraulic Stroke Drilling Power Head | |
| Feeding Travel | mm | 180 | |
| Drilling Diameter | mm | Φ12–Φ50 (Φ12–Φ63 optional) | |
| Main Motor Power | kW | 5.5 (7.5 optional) | |
| Hydraulic Clamping | Clamping Cylinders | pcs | 12 |
| Clamping Power / Piece | kN | 7.5 | |
| Clamping Control | – | Foot Switch | |
| Hydraulic Pressure | MPa | 6 | |
| Precision | Drilling Accuracy | mm | ±0.5 |
| Machine Size | L × W × H | mm | 3500 × 2650 × 2870 |
| Machine Weight | Approx. | T | 6 |
